Manufacturer: Blaw Knox
Age: 1970
Configuration: 11 over 10

Material Speed: 100 - 350 FPM
Material Previously Leveled:
Width: 20" to 60" - Thickness: .012" to .080"
Back Up Rolls:
7 Flights Top & Bottom
Roll Dimension: 2"
Adjustment:
Top: 5 Flights, individually motorized adj.
5-1/2 HP, 29.7 RPM
Bottom: Single motor adjustment
Screwdown Adjustment: 4 screws
(2) motors: 2 HP, 84 RPM
Roll Bend Adjustment: 3 HP, 525 RPM
Motorized Lubrication System: 1 HP, 1200 RPM
Main Drive Motor: 30 HP, 1150/2300 RPM, 230 V. DC

Overall Dimensions:
Length across pass line: 16'4"
Height: 59-7/8"
Width (in direction of material travel): 36"
Pass Line Height: 34-1/4"
